Electrical parameters:

1.Frequency range: 1710-2170MHz 2200-2500MHz 2500-2690MHz

2.Polarization: ±45°

3.Gain: 14.5dbi

4.Down-tilt:0°

5.Horizontal beam width: 32°±5

6.Vertical beam width: 33/28/24

7.Cross polarization ratio: axis direction≥20, ±15°≥15

8.Front-to-back ratio:>28dB

9.VSWR: ≤1.5

10.Isolation degree:>28dB

11.Third order intermodulation: <-107dBm

12.Input impedance: 50Ω

13.Power capacity: 350W

14.Anti-lightning protection: DC ground

Mechanical performance illustration:

1.Product category:2×N female

2.Size (without packet):295*280*80mm

3.Size (with packet):320*300*120mm

4.Weight (without packet):3.1kg

5.Weight (with packet):3.4kg

6.Wind load area：0.427m²

7.Wind resistance: 60m/s

8.Antenna shield material: UPVC

9.Interface position: bottom

10.Mechanical down-tilt: 0~15°

11.Operating temperature: -50~+60℃

12.Pole mounted: ¢50~¢115

13.Limited temperature: -55~+75

14.Operating humidity: 8%~98%

Product feature:

This antenna is widely used with advantages including easy site construction, easy maintenance, low cost and high gain.
